Characteristics of our Lucus E40 Tube Light
We use CREE® X-Lamp Q2, Q4 and Q5 LED chips for highest light output and reliability.
Very low total power consumption: Only 15watts!
High Lumen output: >1,000 Lumens.
Evenly distributed Circular Light Beam. Using our patented reflector cups we have achieved the most economical way to control light.
Fits All Standard E40 Sockets, A Direct Retrofit Replacement.
Easy assembly and Disassembly mechanism.
Changing Power Supply made easy, you don’t need complicated tools to open the case to swap a power supply. .
Smart Heat sink holds it all together using two long screws and maintains highly efficient thermal management.
Less visual fatigue when used with glossy shade.
No need for “Very Hot” warnings.
No more cleaning.
Global Power input: Use it in any country. 80VAC to 260VAC.
Line frequency: 45Hz to 65 Hz.
No Ultraviolet (UV) or Infrared (IR) radiation.
Shock-resistant: No moving parts, delicate filaments or breakable glass.
High precision Driver Board uses National Semiconductors LS3406 Chips to provide constant current and to extend the life span of the LEDS.
RoHS approved and certified to contain no poisonous substance. No lead or mercury.
The energy saved over six months will pay for lamp itself.
Long lasting: guaranteed to provide over 70% of its original luminance for 50,000 hrs.
|
Part Number |
Description |
Quantity |
Parts Photos |
|
6840-010-R1 |
Main Frame |
1 |
|
|
6840-020-R1 |
Top Cover |
1 |
|
|
6840-030-R1 |
Front Cover |
1 |
|
|
6840-040-R1 |
E40 Plastic Base |
1 |
|
|
6840-050-R1 |
Lens Cover |
1 |
|
|
6840-060-R1 |
LED PCB Board |
1 |
|
|
6840-070-R1 |
E40 Base |
1 |
|
|
6840-080-R1 |
Gasket |
2 |
|
|
6840-090-R1 |
Driver board National SC |
1 |
|
|
6840-100-R1 |
Power Supply Board 20W |
1 |
|
|
|
Long Screw |
2 |
|
